Angled NEMA 5-20P Straight Blade Plug – 8 Angled Positions

$7.15

WB520RAP

20A/125V, 2 Pole/3 Wire, Angled, Quality Nylon Construction, Clear & White, Easy-to-follow Installation Instructions, UL/cUL and RoHS Compliant

Please contact us for a higher volume quote.
SKU: WB520RAP Category:

Additional information

Part Number WB520RAP
Rating 20A/125V
Pole 2
Wire 3
Wire Size 18~10AWG
Cable OD .300" to .650"
Material Nylon, Brass
Color Black Body & White Insert

Description

Webber’s Angled NEMA 5-20P Attachable Replacement Plug comes with easy-to-follow Installation Instructions. Our unique, angled design allows for use in 8 different configurations to meet almost any application you may need. This device features Isolated see-thru Wiring Chambers which helps to prevent arcing & flashover during installation of wires for a solid connection. There is an adjustable rear Cord Clamp for attaching a variety of wire sizes (accepts 18~10 AWG). This Grounded 3 Wire, 20 Amp/125 Volt Plug is designed for Commercial and Residential uses. This Wiring Device features high quality, durable nylon construction material and solid brass blades. All our wiring Devices meet UL. cUL and RoHS standards.
